KUDA PRODUCT LINE
| PAPER CUTTERS: | ||
115, 137, 155, 176 |
92, 115, 137, 155, 176 |
|
Display screen |
15” LCD Colour Touch Screen |
8.4” LCD Colour Screen |
Programmable functions |
cutting, maintenance, knife changing, remote diagnosis* |
cutting, maintenance, knife changing |
Clamp pressure adjustments from Touch Screen |
standard |
n/a |
* modem required |
||
 |
 |
SPECIFICATIONS |
K92 |
K115 |
K137 |
K155 |
K176 |
Cutting speed - cycles/min. |
45 cycles |
45 cycles |
45 cycles |
45 cycles |
45 cycles |
Cutting width |
92 cm / 36” |
115 cm / 45 1/4” |
137 cm / 54” |
155 cm / 61” |
176 cm / 69 1/4” |
Cutting depth |
92 cm / 36” |
115 cm / 45 1/4” |
137 cm / 54” |
155 cm / 61” |
176 cm / 69 1/4” |
Clamp opening |
13 cm / 5 1/8” |
16.5 cm / 6 1/2” |
16.5 cm / 6 1/2” |
16.5 cm / 6 1/2” |
16.5 cm / 6 1/2” |
Backgauge speed |
30 cm/sec. |
30 cm/sec. |
30 cm/sec. |
30 cm/sec. |
30 cm/sec. |
Smallest cut without false clamp |
2.5 cm / 1” |
2.5 cm / 1” |
2.5 cm / 1” |
3.5 cm / 1 3/8” |
3.5 cm / 1 3/8” |
Smallest cut with false clamp |
9 cm / 3 1/2” |
9.5 cm / 3 3/4” |
9.5 cm / 3 3/4” |
12 cm / 4 3/4” |
12 cm / 4 3/4” |
Clamp pressure, min./max. |
330 / 7700 lbs |
330 / 9920 lbs |
330 /12100 lbs |
440 / 13200 lbs |
440 / 15430 lbs |
Power requirement |
20 Amp / 4.2 kW |
25 Amp / 5.6 kW |
30 Amp / 6.6 kW |
35 Amp / 8.2 kW |
35 Amp / 8.2 kW |
Net weight |
5500 lbs |
8360 lbs |
9900 lbs |
12760 lbs |
14960 lbs |
Overall width |
95 1/4” |
124” |
132 5/8” |
139 3/4” |
148” |
Overall length |
87 1/4” |
101 3/8” |
114” |
141 3/4” |
141 3/4” |
Overall height |
61 1/2” |
65” |
65” |
68” |
68” |
Table height |
35 1/2” |
35 1/2” |
35 1/2” |
35 1/2” |
35 1/2” |
All technical and appearance specifications are subject to change |
|||||
